HDS Series

Features

• Built-in 100v/70v transformer

• In-ceiling type loudspeaker

• 6.5” +1.5” coaxial speaker unit

• Power output RMS 40W, 30W, 20W @100V

• Built-in crossover for hi-fi level use

• Metal grille, ABS baffle & ABS back cover

• Paint in white color

• Secure flush mount installation

Description

The Heinrich HDS SERIES HEINRICH all speakers support EASE, CATT, ULYSSES models for acoustic studies. This means the acoustic model can be designed to simulate the sound quality and distribution prior to installation. All HEINRICH loudspeaker have undergone trough testing procedure to ensure that all products compliance with LOW VOLTAGE DIRECTIVE (BS EN 60065, 2003) and EMC (BS EN 61000-6-Part 1/2/3/4). These speakers could be easy tted in round cutout using 4T-bar support. We recommend wiring with AWG 16 or larger, stranded wire. For proper phasing, both speakers must be wired alike. Connect red wire to red terminal on speakers and to red or plus terminal on amplier. To control the volume of the speakers locally, use an impendence matching volume control.
